Anti-Graffiti Coating System Specifications

Graffiti Melt Coating is a zero VOC, non- toxic, biodegradable, low odor, paraffin- based emulsion. It can be removed from the surface with a hot water pressure washer or one of our non-toxic, biodegradable removers:

(*) This coating meets the Super Compliant VOC Paint List requirements set forth by the SCAQMD and has been field tested and approved by the City of Los Angeles.

Gold Remover cleans Graffiti Melt from porous, unpainted surfaces such as brick, concrete and masonry.

Eaze Away Remover cleans Graffiti Melt from baked and painted delicate surfaces.

Product Description:

Graffiti Melt is a ready-to-use, low odor, “sacrificial” coating used to protect exterior surfaces from graffiti, posters and atmospheric pollution. Graffiti Melt is composed of water and food grade materials, and creates a tough barrier without altering the appearance or texture of the treated surface. Once the surface is coated, graffiti can be removed with a hot water pressure washer or one of our removers and cold water. After removal, re- apply the Graffiti Melt to the affected area. Removal by any other means will void the Graffiti Melt warranty. NOTE: Some paints, inks and cleaning agents contain harsh solvents and other chemicals that can alter Graffiti Melt by affecting its performance or removing it from the surface altogether. Genesis Coatings makes no guarantees as to system compatibilities - this information must be determined by applying a test patch to the appropriate substrate.

Uses:

  • Concrete
  • Aggregate
  • Buildings
  • Bridges
  • Brick
  • Stucco
  • Walls
  • Fences
  • Block
  • Wood
  • Light Poles
  • Trees
  • Many other painted & unpainted surfaces

Performance:

  • Graffiti Resistant
  • Non-Flammable
  • Fast Drying
  • USDA Compliant
  • Low Odor
  • Breathable
  • Zero VOC
  • Solvent Free

Characteristics:

  • Color:   Clear
  • Finish:   Stain
  • Reduction:   None
  • Curing Mechanism:   Evaporation

Technical Data:

Resin Type:   Paraffin Wax

% Solids by volume:   30%

Dry Time:   (Temperature & Humidity Dependent)

@ 45°F & 75%RH @ 1 mil wet:

To Touch:

Tack-free & Recoat:

Dry Hard:

25 Minutes

45 Minutes

1 Hour

@ 75°F & 50%RH @ 1 mil wet:

To Touch:

Tack-free & Recoat:

Dry Hard:

5 Minutes

15 Minutes

45 Minutes

Full Cure:

Dry Film:

VOC:

Flash Point:

pH:

Specific Gravity:

Flexibility:

Solubility in Water:

Breathable:

Viscosity (D-816):

Product Scent:

EP A Compliant:

CARB Compliant:

24 hours

<1 mil

0

None

9.3

0.98 Kg/l

Slight

Complete

Yes

31 sec @ 77°F

Light Pine

Yes

Yes

Shipping and Packaging:

Graffiti Melt Coating, Gold and Eaze Away Removers are available in various packaging sizes as follows:

Product 22oz 1 Gal 5 Gal 55 Gal
Graffiti Melt ✓ ✓ ✓
Gold Remover ✓ ✓ ✓
Eaze Away Remover ✓ ✓ ✓

Weights & Case Requirements:

  • Gallon (4/case)
  • Five Gallon Pail
  • 55 Gallon Drum

36 lbs.

45 lbs.

465 lbs.

Shipping Classification:   Class 55

*Graffiti Melt Coating and Removers

meet all current standards of the U.S. Environmental Protection Agency as well as meets or exceeds all known EPA, OSHA, and CARB hazardous material requirements for this class of architectural coatings.

KEEP OUT OF REACH OF CHILDREN AND ANIMALS!

Storage:

KEEP FROM FREEZING. Product does not have a freeze/thaw cycle. Take necessary precautions for transporting and storage to keep from freezing. If product does freeze, discard according to local, state and federal regulations.

Containers should be shaken before use and kept closed during storage. Store product unopened for up to 18 months at 50°F to 90°F. Avoid prolonged exposure to sunlight.

Limitations:

  1. Do not apply Graffiti Melt in high heat, wind or rain, or where rain is imminent, or where surface temperatures are below 45°F.
  2. Desired surface pH level must be between 8.0 and 10.0.
  3. Retaining walls, planter boxes or surfaces where water will be of concern must be waterproofed prior to applying Graffiti Melt.
  4. Do not apply Graffiti Melt to horizontal or walking surfaces, as the product becomes slippery when wet.
  5. Graffiti Melt does not promote or prevent efflorescence.
  6. Rolling is not recommended on any surface due to the potential to overcoat.
  7. HVAC runoff can sometimes adhere to the coating to cause streaking.

Coverage and Compatibility:

The following coverage rates are approximate and should be used as an estimate only. Always conduct test applications on actual surfaces to accurately determine coverage rates and compatibility with existing coatings. Porosity, texture, method of application, and climate conditions can affect coverage rates:

Substrate Sq.Ft/Gallon Coats
Metal 600 1
Sealed Wood & Concrete 450 1
Concrete & Painted Block 400 2
Concrete Block & Stucco 300 2
Brick 350 2

Tech Spec

The Tech-Spec Data Sheet conforms to editorial style prescribed by the Constitution Specifications Institute. The manufacturer is responsible for technical accuracy. 02/16/11
