GCP 5000
Urethane/Acrylic Hybrid Base Coat
Product Description
GCP 5000 Series is a superior two component, VOC, Urethane/Acrylic Hybrid coating system. It is designed to provide excellent color and gloss retention, chemical and UV resistance, quicker dry times while maintaining a longer pot life. GCP 5000 has excellent adhesion and durability over a variety of substrates such as polycarbonate, ABS, Kydex & aluminum. When used as a complete system, primer, base coat and topcoat, GCP 5000 provides an easy to maintain, high performance system that will last over years.
Intended Uses:
- Aerospace, Transportation
- Sporting goods
- Telecommunication products
- Consumer electronic products
- Interior automotive
Product Characteristics
Resin Type: Urethane Acrylic Hybrid
Finish: Satin <15° with 60° meter
Colors: Custom Colors
Weight per Gallon: 9.0-11 (varies with colors)
Pot Life: 3 hours
Gel time: >24 hours
Solids by Weight: 30-40% (±2)
Mix Ratio: (weight) 100 parts SO 575 Reducer / 10 parts G Series Activator/100 parts of GCP-5000 base.
Mixed Viscosity: 30-35 seconds #2 EZ Zahn cup 75oF
VOC: <250 g/L
Dry Film Thickness: 1.2-1.5 mils
Dry Time & Cure Schedules (temperature & humidity dependent):
| Dry to Handle: | 30 minutes | @ 150°F |
|---|---|---|
| Dry to Recoat: | 30 minutes | @150°F |
| Tack Free: | 45 minutes | @77°F (RT) |
Surface Preparation & Application Highlights
Surface Preparation: (see application instruction for more detail)
All surfaces should be thoroughly cleaned and degreased, and free of mold and all other impurities.
Mixing Ratio (by weight):
100 parts SO 575 Reducer / 10 parts G Series Activator/100 parts of GCP-5000 base.
Application: (see application instruction for more detail)
Spray viscosity is 30-35seconds #2 EZ Zahn cup. Spray with conventional or HVLP spray gun to achieve 1.2-1.5 mils DFT.
Packaging
1 gallon Base
1 gallon SO 575 Reducer
1 pint G-Series Activator
This product is shipped as Class 55 Hazardous.
Product System Options / Compatibility
GCR-37MT Series – Genesis Metallic colors
GCR-37B Series – Genesis Solid Color Topcoat : available in Gloss (>80), Semi-gloss (50), Satin (25), Flat (<5)
GCR-37B-C5M1 – Clear Gloss Topcoat
GCP-3001 – Genesis Soft Touch Topcooat
ASTM Testing
ASTM Test Results:
Substrate – Steel
Preparation – SSPC-SP10
2 Coats – GCP 5000 Acrylic Solvent-borne
Abrasion ASTM D4060 (CS17 wheel/1000 cycles/ 1kg load) Result = 107 mg loss
Adhesion ASTM D4541 = 500 psi
Direct Impact Resistance ASTM D2794 = >160 in. lbs.
Dry Heat Resistance ASTM DD2485 = 300°F
Flame Spread Rating ASTM E84-91A/ASTM E162
Result: Flame Index Spread – 5/Smoke Density Index – 0
Flexibility ASTM D522 (180° bend, 1/8”mandrel) = Passes
Hardness ASTM D3363 = 2B
Moisture Condensation Resistance ASTM D4585
Result: 100°F, 300 Hours = Passes
Salt Spray ASTM B117 (500 hours) = Excellent
Smoke Emissions ASTM E662 Flaming/Non-Flaming @1.5 = 0; Flaming @ 4 = 11; Non-Flaming = 2
Comparable to products formulated to federal specification: Mil- P-28578B, anTT-P-1511B & Paint Specification: SSPC-Paint 24
See additional Information for chemical resistance.
FOR INDUSTRIAL USE ONLY.
Theoretical Coverage Rates
Spread rate is dependent on application method, substrate and anticipated level of use. Below figures are for estimation purposes only. Testing should be completed for accurate figures. Application loss factor is not covered due to surface profile, porosity, application technique, surface irregularities, spillage, climatic conditions or film build:
Spread @ 1 mil: 420-450 square feet (theoretical)
100% transfer efficiency
Storage
Store unopened at 45°F - 90°F.
Keep from freezing or prolonged exposure to sunlight and heat.
Contact Information
The information provided is to be used as guidelines only. Specific jobs may require additional information. Please contact Distributor or GCR Representative at (800) 533-4273 for further information. Refer to the Application Instructions and Material Safety Data Sheet for more detailed information.
